Seamless Mechanical Steel Tubing For Hydraulic Components
Mechanical pipelines are divided into mechanical hoses and hard pipes, but each has its own advantages and disadvantages in terms of structural characteristics and use effects. Hard pipes have a larger bending radius than hoses, can withstand higher temperatures, and have a more compact layout. However, hoses have better shock absorption, better flexibility, and can connect moving metal parts than hard pipes.
Specification
Production Range
Outer Diameter:10-120mm (0.4 inch - 4.7 inch)
Wall Thickness:1-20mm (0.04 inch - 0.78 inch)
Material / Grade
Carbon Steel:
GB/T 8162 & 8163 & 3639: 10#, 20#, 35#, 45#, 55#, Q235B, Q235C, CF53, A105
ASTM A519: 1010, 1020, 1026, 1035, 1045, 1050
DIN17121/EN 10297-1, DIN1629/DIN2391/EN 10305-1: C10/CK10, C22/CK22, C35/CK35, C45/CK45, CF53
JIS3441/JIS3444/JIS3445: STKM11A, STKM12A/STKM12B/STKM12C, STKM13A/STKM13B/STKM13C
JIS G4051: S10C, S20C, S25C, S35C, S45C, S55C
Alloy Steel:
GB/T 8162 & 8163 & 3639: 16Mn(Q345B), 20Cr, 40Cr, 15CrMo, 20CrMo, 28CrMo, 30CrMo, 35CrMo, 42CrMo, 20CrMnTi, 40MnMoV, 20Mn2, ZF6, 16MnCr5, 20MnCr5, 38Mn2V, 09CrCuSb(ND)
ASTM A519: 5120, 5140, 4130, 4135, 4140
DIN17121/EN 10297-1, DIN1629/DIN2391/EN 10305-1: ST52, EN10084-1998 20Cr4, 41Cr4, 15CrMo4, 25CrMo4, 35CrMo4, 42CrMo4, 16MnCr5
JIS3441/JIS3444/JIS3445: SCM432/SCRRM3, SCM4
JIS G4053: JIS SCr420, JIS SCr440, SCM415, SCM420
Tolerance
Tolerance ±0.15mm,Superior products ±0.05mm, Can be customized according to customer's requirements
Technique
Cold Drawn / Cold Rolled / Hot Rolled
Shape
Round
Further Processing for Steel Tubes
Final Annealing, Cutting, Chamfer, Threading, Inner diameter or Outer Diameter Lathe, Surface Shot Blasting, Laser Marking
FAQ
Q1. Are you a manufacturer or trader?
We are a manufacturer, and we can have our own factory produced many steel products.
Q2. Whether your company supports Trade Assurance order?
Yes, we can (100% product quality protection; 100% on-time shipment protection; 100% payment protection)
Q3. Can we get the some samples? Any charges?
Yes, you can get available samples in our stock. If the samples from new production, we will charge some reasonable cost, but this amount will be deducted from your first order.
Q4. How do we build up business relations with your company?
Send us your requirement which includes size, coating info, parameters, quantity, destination .
Q5. What is the MOQ?
We can accept small orders. Please feel free to contact us, we can meet your requirements.
Q6. What's your advantage?
With high-quality products and efficient customer service, we adhere to the principle of customer first.
Q7. How long is your delivery time?
Delivered within 15 days after receipt of deposit.
Alloy Seamless Steel Tube/Round Hollow Structural Steel Pipe
Hot-rolled seamless steel pipes are generally produced on automatic pipe rolling units. After inspecting and removing surface defects, the solid tube blank is cut to the required length with the end face of the perforated end of the tube blank as the center, and then sent to the heating furnace for heating and perforated on the piercing machine. While piercing, continue to rotate and advance. Under the influence of the rollers and the end, the tube blank is gradually hollowed out, which is called a capillary tube. Then it is sent to the automatic pipe rolling machine for continuous rolling, and the sizing machine is used to determine the diameter, and the homogenizer is used to level the wall thickness to meet the specification requirements.
Specifications
Item
Structural Seamless Steel Pipe
Tolerance
-1%+1%
Length
12m, 6m, 6.4m, 1m, 13m, Customer′s Requirements
Oiled or Non-Oiled
Non-Oild
Usage
Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe, Oil/Gas Drilling, Food/Beverage/Dairy Products, Machinery Industry, Chemical Industry, Mining, Construction & Decoration, Special Purpose
Special Pipe
API Pipe, Other, EMT Pipe, Thick Wall Pipe
Weight
Actual Weight or Theorectical
MOQ
1 Ton
Application
The scope of use of structural seamless steel pipes includes general building structures and mechanical structures, such as steel structure workshops, automobile chassis, plastic machinery, etc. At present, structural seamless steel pipes have been widely used in construction, machinery, transportation, aviation, oil exploration and other industries.
Seamless Steel Pipe for Low Medium High Pressure Boiler
Seamless boiler tubes are specifically designed to withstand high temperatures, pressures, and corrosive environments associated with boiler systems. Their seamless construction, high-temperature resistance, corrosion resistance, and dimensional precision make them essential components for reliable and efficient boiler operations.
Specifications
Type
Main Material
Operational Standard
Specification
Use
Alloy Pipe
P5/T5, STFA25, P11, P12, STFA22, 13CrMo44, 12Cr1MoV, P22, 10CrMo910, T91/P91, P9/T9, WB36
GB5310-2008
∮16-426×2-90mm
Petroleum Chemical Industry, Electric Power, High Temperature Resistant
GB9948-2006
ASTM A335/A335M
ASTM A213/A213M
DIN17175-1979
JISG3467-1988
JISG3458-1988
High Pressure Boiler Pipe
20G, 12Cr1MoVG, 15CrMoG, ST45.8/III
GB5310-2008
∮16-824×2-65mm
Heat Resistant Seamless Steel Pipe Used for High Pressure Boiler
ASTM A106-1999
DIN17175-1979
Petroleum Cracking Pipe
20, 1Cr5Mo, 15CrMo
GB9948-2006
∮10-530×1.5-36mm
Petroleum Refinery Furnace Tube, Heating Exchange Pipe, Seamless Pipe Used in Conduit
Pipe for chemical fertilizer facility
20, 16Mn, 12Cr2Mo
GB6479-2000
∮25-426×6-40mm
Chemical Fertilizer Facility Pipe
Low or Middle Pressure Boiler Pipe
10, 20
GB3087-2008
∮10-426×2-40mm
Low Pressure Boiler Heating Exchange, Boiling Water Pipe, Vehicle Vent-pipes
Fluid Pipe
20, Q345
GB/T8163-2008
∮8-610×1.5-40mm
Fluid Transportation
Structure Pipe
20, 45, 40Cr, Q345
GB/T8162-2008
∮6-610×1.5-40mm
In General Structure
Pipe of Pipelines
B, X42, X52
API 5L-2000
∮40-325×3-40mm
Petroleum, Gas transportation
Pipe for Hydraulic pressure Cylinder
20, 45, 27SiMn
GB/T17396-1998
∮70-377×12-40mm
Hydraulic Pressure Bracket
Pipe for Manage ship
360, 410
GB/T5312-1999
∮14-426×2-45mm
Make shipping to use and manage
Oil Pipe
J55, K55, N80, L80, P110
API 5CT-2005
∮60-114×4-12mm
Transmission oil pipeline
Drill Pipe
E75, X95, G105, S135
API 5D-2001
∮60-139×6-13mm
Oil well drilling
Casing Pipe
J55, K55, N80, L80, P110
API 5CT-2005
∮114-273×4-13mm
Oil well wall lining
Characteristics of Seamless Boiler Tubes:
High-Temperature Resistance: Seamless boiler tubes are manufactured from materials that can withstand high temperatures generated in boiler systems. Common materials used for seamless boiler tubes include carbon steel, alloy steel, and stainless steel. These materials offer excellent heat resistance, ensuring the tubes can handle the extreme temperatures and thermal stresses associated with boiler operations.
Seamless Construction: Seamless boiler tubes are produced using a seamless manufacturing process, which involves heating a solid steel billet and then piercing it to form a hollow tube. This seamless construction eliminates the presence of welds or joints, which can be potential weak points in the tube. The absence of welds enhances the strength and integrity of the tubes, making them more reliable in high-pressure and high-temperature environments.
Corrosion Resistance: Seamless boiler tubes are often made from materials with good corrosion resistance properties. Stainless steel and certain alloy steels, such as chrome-molybdenum (chrome-moly) steel, offer excellent resistance to corrosion and oxidation at elevated temperatures. This corrosion resistance helps to maintain the integrity of the tubes, ensuring long-term reliability and minimizing the risk of failure or leaks.
Dimensional Precision: Seamless boiler tubes are manufactured with precise dimensions to meet the requirements of boiler systems. They are available in various sizes, diameters, and thicknesses, allowing for customization to specific project needs. The dimensional precision of the tubes ensures proper fit and compatibility with boiler components and facilitates effective heat transfer.
High Pressure Resistance: Seamless boiler tubes are designed to withstand high-pressure conditions commonly found in boiler systems. They are engineered to handle the internal pressures generated by the steam or fluid circulating within the boiler. The tubes' strength and durability enable them to withstand the stress and pressure without deformation or failure, ensuring safe and efficient operation.
Carbon Steel ASTM Hot Rolled Seamless Steel Pipe
Specifications
Products name
Hot rolled seamless steel pipe
Thickness
Sch40-sch80 or according to clients request
OD
12mm-800mm
WT
0.5mm-20mm
Stock
Normal thickness can supply from stock
Length
1-12m
Sruface Treatment
bare, oiled, galvanized, coating, painting, etc
Output Capacity
200000 tons per year
MOQ
1 ton
Usage
structure pipe, water pipe, oil and gas pipe, etc
Here are some key characteristics and features of hot rolled seamless steel pipes:
Manufacturing Process: Hot rolled seamless pipes are produced by heating the steel billet or ingot to a temperature above its recrystallization temperature and then rolling it through a series of rolling mills. The hot rolling process ensures a smooth and uniform surface finish.
Size Range: Hot rolled seamless pipes are available in a wide range of sizes, from small diameters to large diameters. This versatility allows for various applications and requirements in different industries.
Strength and Durability: Hot rolled seamless pipes are known for their high strength and durability. The hot rolling process enhances the mechanical properties of the steel, making it suitable for applications that require resistance to high pressure and stress.
Wide Application: Hot rolled seamless steel pipes find applications in various industries, including oil and gas, construction, infrastructure, machinery, and automotive. They are commonly used for conveying fluids, gas, and steam in high-pressure environments.
Cost-Effective: Hot rolled seamless pipes are generally more cost-effective compared to cold drawn or cold rolled seamless pipes. The hot rolling process is less complex and requires fewer manufacturing steps, resulting in a relatively lower production cost.
Surface Finish: Hot rolled seamless pipes have a characteristic scale or oxide layer on their surface, known as mill scale. This layer can be removed through a process called descaling if a smoother surface finish is desired.
Availability: Hot rolled seamless pipes are readily available in the market due to their wide production and popularity. They can be sourced from steel mills, distributors, and suppliers specializing in steel pipe products.
Cold Drawn Seamless Carbon Steel Pipe For Gas Conveyance
Shandong Fengbao Metal Products Co., Ltd is a manufacturer and supplier of Seamless Carbon Steel Pipe products for various uses. The carbon steel comprises of carbon and iron for the most part. Trace amounts of silicon, manganese and copper are allowed in different quantities depending on the grades. The Carbon Steel Seamless Pipe material therefore is stronger and is highly stress resistant. These properties make the pipes be applicable in heavy duty services.
Specifications
NAME
Cold Drawn Seamless Carbon Steel Pipe
STANDARD
ASTM, GB, API, JIS, BS, DIN, YB, SNY, etc
MATERIAL
10#,20#,45#,A53A,A53B,A106Gr.A,A106Gr.B,A106A,A106B,ST52,ST358,16Mn,
Q235, Q195, Q345, Q215, API 5L Gr.B,Gr.65,Gr.60,Gr.70,
X42,X52,X60,X65,X70,X80,etc
SPECIFICATION
Outer diameter: 15mm-1626mm
Wall thickness: 2mm-30mm
Length: 6m-12m or as requested
SEAM
SAW(Spiral welded),SSAW(Spiral submerged-arc welded),HSAW,(Helical Submerged Arc
Welded), ERW,
SURFACE
Black painted, PE/PVC/PP coated, Galvanized, color coated, anti rust varnished,
anti rust oiled, checkered, epoxy coating, etc.
END
plain end, spigot & socket joint, beveled, cut square, flanged, piling shoes
END PROTECTOR
1) Plastic pipe cap
2) Iron protector
PACKAGE
Standard export package, suit for all kinds of transport or as required.
PRICE TERM
EXW, FOB, CFR, CIF, etc.
PAYMENT TERM
T/T, L/C at sight, etc.
APPLICATION
1) General service for industries ( petroleum, chemical, aviation, etc.)
2) Fluid, gas and oil transport,
3) Press and heat transmission,
4) City construction, etc.
CONTACT
Please inform us if any item is interesting to you.
Descriptions
Grades
Structural pipe
20# 35# 45# Q345B, 16Mn, Q345B-E, 20Mn2, 25Mn, 30Mn2, 40Mn2, 45Mn2
SAE1018, SAE1020, SAE1518, SAE1045.
Liquid pipe
20# q295b-e, q345b-e
High pressure boiler tube
20G 15MnG 20MnG 15CrMoG, 12Cr1MoVG
St35.8, sa106b, sa106c, sa210a, sa210c, A333P2, A333P11, A33P12, A333P22, A33P36, A333P91, A333P92, A335T2, A335T11, A335T12, A335T22, A335T91, A335T23, A335T9
Pipeline
API SPEC 5L, X42, X52, X60, X65,X70,X80
ASTMA53, ASTM A106, ASTM A333, BS301, BS3602, BS3603, BS3604, PSL1, PSL2, DNV-OS-F101, CSA-Z245
Alloy pipe
4140, 42CrMo, 32CrMo, 15CrMo,
Packing
Black paint, Varnish painting, Tarpaulin packing
End
Common round end, beveled.
Processing
Galvanizing; cutting; making thread outside the pipe; Machining.
Application
Carbon steel seamless pipes are extensively applied in the nuclear device, gas conveyance, petrochemical, shipbuilding and boiler industries, with characteristics of high corrosion resistance combined with suitable mechanical properties.
- Nuclear device
- Gas conveyance
- Petrochemical industries
- Shipbuilding and boiler industries
Honed Seamless Steel Pipe for Hydraulic and Pneumatic Systems
Specifications
Product name
hydraulic cylinder tube /honed tube /seamless honed steel tube
Standard
GB/T3639-2000 DIN2391 EN10305 ASTM A519
Metarial
C20 CK45 Q355B Q355D E355/ST52 SAE1026 4130 4140 STKM 13C
Heat treatment
BK+S
Size
I.D:30mm-400mm
O.D:40mm-480mm
Length
Fixed length ,Random length or as requests of customers
Straightness
0.5-1/1000
ID roughness
RA 0.1-0.8micron(max)
Payment term
FOB, CFR, CIF,EXW, FCA and so on
Application
Honed tube for hydraulic cylinder,swivel crane,injection machine and construction machine application
Conservation
anti rust oiled inside and outside surface, plastic caps in both ends
Package
bundle with steel strip and knitting strip, or wooden case
Application
Honed seamless tubes are commonly used in industries such as hydraulic and pneumatic systems, automotive, aerospace, and precision engineering. They are often used as cylinder barrels, piston rods, and other components that require precise dimensions, tight tolerances, and excellent surface quality.
1) All standard steel products are stocked, timely shipping as per clients request.
2) Lead time generally about 15-30 working days after receiving the deposit.
3) Standard export package,suit for all kinds of transport,or as required.
4) If special requirements, may need longer delivery time.
5) Loading port: As required.
